CIM 30 Spring Loaded Uni-Directional (NRV)

CIM 30 Spring Loaded Uni-Directional (NRV)
CIM 30 Spring Loaded Uni-Directional (NRV)
Product Code : CIM 30
Brand Name : CIM
Product Description
Spring Loaded Uni-Directional (NRV)

Item Code: CIM-30

SPRING LOADED check valve (NRV) can be used for domestic & industrial plumbing, heating & pneumatic systems, oil & petrol services etc. Handling water, air, vacuum etc. Suitable for Vertical/ Horizontal or Oblique Pipelines, allows Flow in one direction only.

Main Features:


The spring loaded inner valve opens and lifts under pressure of 25 mbar (0.36 psi), very low pressure drop, prevents water hammer, compact design, noiseless operation, dent-proof Hostaform soft seating. Full flow area equal to nominal size.

Specification:

Body

Forged brass,

Spring

Conical tempered spring in S.S. 316,

Inner Valve

Hostaform,

Valve Face

NBR rubber, Ends Screwed BSP female x female end.

Test Pressure

Shell 30Kg. Seat 22Kg.

Pressure Rating

Fluids 20Kg. Saturated steam 7Kg

Temperature Rating

Fluids -10°C to +95°C.

Size

1/2" to 2"
